Model:BFX6432
Vertical Spindle:
Table Center To Vertical Spindle:190~510mm
Table Center To Vertical Column:215~470mm
Spindle Taper:7:24 ISO50
Steps Of Spindle Speed:12
Range Of Spindle Feed:60~1750rpm
Horizontal Spindle:
Spindle Taper:7:24 ISO50
Steps Of Spindle Speed:18
Range Of Spindle Feed:30~1500rpm
Distance Spindle Nose To Table:30~350mm
Distance Spindle Center To Ram:155mm
Worktable:
Working Table Size:1325×320/1600x320mm (Optional)
Max Longitudinal Travel:680/700mm or 880/900mm
Max Transverse Travel:240/255mm
Max. Vertical Travel:300/320mm
Table Feed Range:8~394mm/min
T-Slot Of Table(Number/Width/Distance):3/18/70mm
Table Of Swivel:±45°
Main Motor:7.5kw(H)/4kw(V)
Feed Motor:1.5kw
Packing Size:2020x1700x1994mm
N.W.:3000kg
Boasting 900mm maximum longitudinal travel, BFX6432 enables large-scale hardware machining with seamless feed movements. What sets it apart is the two optional working table sizes, adapting flexibly to diverse hardware parts—from small fittings to large components. 3000kg 900mm max. longitudinal travel two optional working table size universal milling machine for hardware machining eliminates the need for multiple devices, cutting operational costs.
3000kg 900mm max. longitudinal travel two optional working table size universal milling machine for hardware machining balances power and versatility, perfect for hardware workshops pursuing productivity and quality. This universal milling machine excels in drilling, grooving and contouring hardware. For businesses seeking a reliable, adaptable hardware processing tool, 3000kg 900mm max. longitudinal travel two optional working table size universal milling machine for hardware machining is the ultimate investment to boost competitiveness.
