Model:BT500A
Turning Diameter (Max.):∅500mm
Swing Over Cross Slide:∅330mm
Swing In Gap Diameter:∅660mm
Valid Length Of Gap:200mm
Distance Between Centers:1000/1500/2000mm
Center Height:250mm
Width Of Bed:360mm
Spindle Nose:ISO-C6 or ISO A2-8
Spindle Bore:∅52 or Ø82mm (Optional)
Taper Of Spindle Bore:MT6 or MT8
Spindle Speed (9 Steps):40~1400rpm
Top Slide Travel:95mm
Cross Slide Travel:250mm
Max. Section Of Tools:20x20mm
Range Of Metric Threads (29 Kinds):0.25~14mm
Range Of Inch Threads (33 Kinds):2~40T.P.I
Threads Diametral Pitches (50 Kinds):4~112D.P
Threads Module Pitches (17 Kinds):0.25~3.5M.P
Tailstock Quill Diameter:∅75mm
Tailstock Quill Travel:150mm
Taper Of Tailstock Quill:MT5
Motor Power:5.5kw
Coolant Pump Motor:90w
Rapid Drive Motor:125w
Voltage:380V~440V(3PH)
Packing Size:(2430/2930/3430)x1130x1800mm
9-Step speed 52mm/82mm spindle bore lathe with foot brake for multi – variety parts production redefines versatility and safety for multi-variety parts production, engineered with 9-step speed regulation to adapt seamlessly to diverse machining demands.
Equipped with dual spindle bore options (52mm/82mm), 9-Step speed 52mm/82mm spindle bore lathe with foot brake for multi – variety parts production handles small to medium-sized workpieces with precision, making it ideal for aerospace, automotive, and medical component manufacturing.
Its robust foot brake system ensures instant, smooth stopping, enhancing operational safety and reducing workpiece damage risks during quick adjustments. Designed for flexible production, 9-Step speed 52mm/82mm spindle bore lathe with foot brake for multi – variety parts production minimizes changeover time between part types, a game-changer for small-batch, multi-variety workflows. Elevate your manufacturing line with the BT500A lathe that merges safety, adaptability, and durability—perfect for modern precision machining needs.
